Project Description
Nominal Wt. per 100Ft(30.5M) |
Nominal Wall Thickness |
||||||
U.S. |
Metric |
Lbs |
Kg |
In. |
mm |
In. |
mm |
16 |
30 |
13.5 |
0.706 |
17.93 |
0.042 |
1.07 |
|
3/4 |
21 |
46 |
20.7 |
0.922 |
23.42 |
0.049 |
1.24 |
1 |
27 |
67 |
30.6 |
1.163 |
29.54 |
0.057 |
1.45 |
1-1/4 |
35 |
101 |
45.6 |
1.510 |
38.35 |
0.065 |
1.65 |
1-1/2 |
41 |
116 |
52.8 |
1.740 |
44.20 |
0.065 |
1.65 |
2 |
53 |
148 |
67.2 |
2.197 |
55.80 |
0.065 |
1.65 |
2-1/2 |
63 |
216 |
97.9 |
2.875 |
73.03 |
0.072 |
1.83 |
3 |
78 |
263 |
119.3 |
3.500 |
88.90 |
0.072 |
1.83 |
3-1/2 |
91 |
349 |
158.3 |
4.000 |
101.60 |
0.083 |
2.11 |
4 |
103 |
393 |
178.3 |
4.500 |
114.30 |
0.083 |
2.11 |
Applicable Tolerances:
Length: 10Ft (3.05m) ± ¼” (±6 mm).
Outside Diameter: ½”-2” ±0.005” (±0.13mm); 2½” ±0.010” (±0.25mm); 3” ±0.015” (±0.38mm); 3½”-4” ±0.020” (±0.51mm)
Specifications:
East Conduit EMT pipe is manufactured in accordance with the latest edition of the following:
- American National Standard for Rigid Steel EMT (ANSI® C80.3)
- Underwriters Laboratories Standard for EMT-Steel (UL797)
- National Electric Code® 2002 Article 358 (1999 NEC® Article 348)
